Depalletization of jars and cans for food industry
High-performance and reliable depalletizing machine AD662 for an international client in the food industry for cans and glasses.
Depalletization brings number of benefits that increase the efficiency and safety of operations while reducing operating costs.
ADVANTAGES: Minimal space, maximum performance, goods friendly, modularity, flexibility of the production process.
| Basic descripcion | Depalletiser of full cans or glasses with steel (magnetic) lid,low outfeed |
| Guaranteed machine performance | 5 layers / 2min |
| Handled goods – dimensions/weights/orientations | Cans: 0,5 l – pr.75mm; h=109,5mm; weight 0,49kg
0,75l – pr.86mm; h115,4mm; weight 0,75kg
1l – pr.99; h=118mm; weight 0,98kg Glasses |
| Number of products per layer | Cans: 0,5l – 225ks/layer; 2250ks/pal.; 120kg/layer; arrangement 15×15
0,75l – 169ks/layer; 1690ks/ pal.; 130kg/layer; arrangement 13×13
1l – 121ks/layer; 1210ks/pal.; 130kg/layer; arrangement 11×11 |
| Number of layers on pallet | Cans: 10 layers |
| Layer pads between layers (number) | 1200x1000x2-3mm; 200g/m2; |
| Pallet dimensions, material and oreintation | pallete 1000x1200mm; |
| Number of empty pallets in the stack | 10 |
| maximum pallet hight | 1500mm |
| Product change – method | Automatic from operator panel |
| Shift operation | 24 hours/ 5 days/week |
